نسيج حافة أسلوب :
1 ) برجمة التوجيهية : برجمة التوجيهية على طرفي السلك ( اختصار ك )
2 ) برجمة شائكة : الأسلاك الشائكة في الجزء السفلي من برجمة ، وعلى رأس الملتوية في الحافة الشائكة ( ك )
3 ) الشائكة : أسلاك حديد مشدود في كلا نهايات إلى حافة الشائكة ( اختصار ل BB )

تصنيف

نظام سياج من الأسلاك الشائكة ، المجلفن النسيج ، وارتفاع 2.4M ، والأسلاك الشائكة مع الإطار Y ، العمود الصلب ، ويمكن أن تستوعب اثنين 300mm ارتفاع 6 صفوف بالإضافة إلى 6 صفوف من الأسلاك الشائكة مع صف مستقيم ( طول الذراع 500mm ) ، والأسلاك الشائكة ، 2.4 متر × 8 متر باب السيارة واسعة ، مع قفل آلية ، 2.4 متر × 2 متر باب المشاة واسعة ، مع قفل آلية ;

Chain link Fence, Galvanized 4 meter height, Barbed wire for perimeter fencing top,Post for Gate / change of direction posts and angle posts,Y frame Steel posts to accept double 300mm height of 6 plus 6 linear rows of barbed wire (arm length 500 mm), Razor Wire tops, Vehicle gates 4 mts x 8 meter wide, with padlock mechanism, Pedestrian gate with 2,4 x 2 meter padlock mechanism;

framed Chain link commercial fence in 6' and 8' width with 10 gauge galvanized wire;
Vinyl coated, chain link residential fence with 1 single gate and 2 drive gates;
Galvanized chain link fence to Italy;
Plastic-Coating galvanized mesh fence, 2.5" opening, 2.5mm wire diameter and 1.2m high, 12 x 15m mesh rolls ( or 6 x 30m rolls ), for Australia and other countries;
Temporary fence;
Beige Color Chain link Fence, Mesh Opening : 50mm, Wire diameter : 3.50mm after coated, Length of the roll : 15m, Width of the roll: 2m, Column: Galvanized and coated with beige-colored, 2600 x 2.5 inch x 3mm wall thickness, the end of the column: italic angle of 45 degrees with 3 slots to enter Barbed wire, Barbed wire: thickness 3 mm after coated. All the items are galvanized and beige-colored coated, shipping to Saudi Arabia.
Mesh fence in vinyl coated wire (PVC) or galvanized before weaving (GBW) wire.

PVC COVERED MESH, BOUNDARY FENCE, FOR GARDENS, YARDS, PLAYGROUND

Technical data:
- Galvanized iron wire with Plastic-Coated (PVC);
- Color: Green.
- Mesh: 50x50mm;
- Wire diameter: 2,5-2,8mm
- Width of the roll: 2000mm
- Length of the roll: 20mt
For Ukraine and other countries.

PERIMETER SECURITY FENCE FOR AIRPORT TERMINAL BUILDINGS & FACILITIES

Chain-link Fence Fabric:

Edge: Selvage knuckle or twist.
Steel Wire Fabric: Polymer coated wire with a diameter of 3.76mm
Mesh size: 44mm
metallic zinc coating: 366 gram per square meter, zinc coating applied after weaving.
Fence framing:
Posts and Rails: Round cold-formed, electric-resistance-welded, steel pipe or tubing.
Posts and rails and frames protected with an external coating of zinc, and polymer film.
metallic-coated steel tension wire: 4.5mm
Zinc coating weight: 610 gram per square meter by hot dip process.

ANTI CLIMBING HIGH SECURITY FENCING SYSTEM

Fence Panels & Posts: Galvanized wire mesh, gauge 9, diamonds 2 3/8inch, 8' high, with Fence posts, 1 5/8"x21'center runners， Fence posts, 3 inch x 20' gates posts; Tension bar, 3/16"x3/4"x95". For projects in Republic of Mauritius.

Concertina wire, single coil barbed tape concertina with long blade, 450mm in diameter, fabricated from 0.6mm (0.05mm tolerance) galvanized steel strip, 2.5mm (0.1mm) diameter high tensile (220,000 psi) galvanized wire, 33 loops per coil.
